PSG-115-140 Shear Cut Holder

The PSG-115-140 shear cut top knife holder has long been considered to be a “workhorse” of the slitting industry because of its ruggedness, long life, and quality of cut. The holder can cut a wide variety of heavy materials with slit widths down to 115mm (4.56”) while operating at line speeds up to 1,524 meters per minute (5,000 feet per minute). Capable of mounting on a T-bar, dovetail, or any other mounting configuration, the circular top knife holder weighs 8.9kg (19.6 lbs.) and is designed with a 3mm (0.12”) horizontal side stroke that minimizes setup efforts. This top knife holder also includes an adjustable stop that easily changes the side force between top and bottom circular knives in order to maximize knife life and edge cut quality. Features include optional Easy-Set tab, durable dual row bearing lower head design, 140mm (5.51”) diameter circular blade and a TWO YEAR WARRANTY! When your operation requirements demand slitting know-how, heavy duty performance, and long life – call Dienes for answers.

Download the PSG-115-140 Shear Cut Holder Parts List

Request Info
Compare Products
Categories: ,


Additional information

Item #

Mounting

Minimum Slit Width Inches

Maximum Web Speed

5,000 fpm

Operating Pressure

55 to 90 psi

Features

Warranty

Dienes Part #

Providing Custom Quotes on All Products. At Your Request.
